ED40-437 Specification
FDMG-AV1(S) Series 7
4.2 50Hz (For Thailand)
Note: ∗1. The above data are based on the following conditions.
∗2. Capacities are gross, not including a deduction for cooling for indoor fan motor heat.
∗3. Capacities are net, including a deduction for cooling for indoor fan motor heat.
∗4. Please see fan characteristic documents in detail.
Model
Indoor Unit FDMG71AV1S FDMG100AV1S FDMG125AV1S
Outdoor Unit
V1 RG71AV1S R100FUV1S —
Y1 RG71AY1S R100FUY1S R125FUY1S
∗1 Cooling Capacity
(1) ∗2 / (2) ∗3
kW 8.8 / 8.4 10.6 / 10.2 13.1 / 12.6
Btu/h 30,000 / 28,800 36,100 / 34,800 44,500 / 43,000
kcal/h 7,600 / 7,200 9,100 / 8,770 11,200 / 10,800
Indoor Unit FDMG71AV1S FDMG100AV1S FDMG125AV1S
Dimensions H×W×D mm 305×1,350×680 305×1,550×680 305×1,550×680
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 3×12×1.75 3×12×1.75 3×12×1.75
Face Area m² 0.290 0.340 0.340
Fan
Type Sirocco Fan
Motor Output W 125 225 225
Rated Air Flow ∗4 m³/min 23 34 37
Rated Ext. Static Pressure ∗4 mmH
2
O 8.5 10.1 9.8
Mass (Weight) kg 43 51 52
Piping Connections
Liquid mm φ 9.5 (Flare) φ 9.5 (Flare) φ 9.5 (Flare)
Gas mm φ 15.9 (Flare) φ 19.1 (Flare) φ 19.1 (Flare)
Drain mm 3 / 4 B (O.D.φ27.2 I.D.φ21.6) 3 / 4 B (O.D.φ27.2 I.D.φ21.6) 3 / 4 B (O.D.φ27.2 I.D.φ21.6)
Remote Controller
Wired KRC47-1 KRC47-2 KRC47-4 KRC47-1 KRC47-2 KRC47-4 KRC47-1 KRC47-2 KRC47-4
Wireless ———
Outdoor Unit
V1 RG71AV1S R100FUV1S —
Y1 RG71AY1S R100FUY1S R125FUY1S
Color Ivory
Dimensions H×W×D mm 816×880×370 1,215×880×370 1,215×880×370
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 2×36×2.0 2×54×2.0 2×54×2.0
Face Area m² 0.642 0.962 0.962
Comp.
Model
V1 H23A35QABKA H23A46QABKA —
Y1 H23A35QDEEA H23A46QDBEA H23A56QDBEA
Type Hermetically Sealed Reciprocating Type
Motor Output kW 2.2 3.0 3.75
Fan
Model P45J11SM P45J11SM P45J11SM
Type Propeller
Motor Output W 50 75+35 75+60
Air Flow Rate m³/min 46 80 87
Mass (Weight) kg
V1 87 117 —
Y1 84 109 110
Piping Connections
Liquid mm φ 9.5 (Flare) φ 9.5 (Flare) φ 9.5 (Flare)
Gas mm φ 15.9 (Flare) φ 19.1 (Flare) φ 19.1 (Flare)
Drain mm φ 26.0 (Hole) φ 26.0 (Hole) φ 26.0 (Hole)
Safety Devices
Thermal Protector for Compressor, Outdoor Fan Motor and Indoor Fan Motor. High Pressure Switch.
Over Current Relay (Compressor). Reverse Phase Protector. Fuse.
Capacity Step % 100–0 100–0 100–0
Refrigerant Control Capillary Tube
Ref.
Piping
Standard Length m 5 5 5
Max. Length m
50 (Equivalent Length 70m)
50 (Equivalent Length 70m) 50 (Equivalent Length 70m)
Max. Height Difference m 30 30 30
Refrigerant
Model R22 R22 R22
Charge kg 2.4 (Factory Charge for 5m) 2.4 (Factory Charge for 5m) 2.8 (Factory Charge for 5m)
Ref. Oil
Model Refer to the name plate of compressor.
Charge L 1.48 1.63 1.63
Drawing No. 3D049514
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Hz, Volts Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB, 24°C(75°F)WB
5m (Horizontal)
50Hz, 220V
(380V)
—
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB, 24°C(75°F)WB
7.5m (Horizontal)
50Hz, 220V
(380V)
—
