KGA 770
English
42
A factory-new battery is not fully
charged.
Recommendation: Fully charge the
battery before using it for the first time.
Fitting the Battery
N Insert the battery (1) in the power
tool – the battery slides into the
compartment – press it down
carefully until it snaps into position
the battery must be flush with the
top of the housing.
Switching on the Machine
N Set the on/off switch to I.
Side brooms and roller brush begin to
rotate.
Height Adjustment of Side Brooms
The height adjusting knob enables the
side brooms to be set to suit the surface
being cleaned.
N Turn the knob to the required
setting:
Side broom bristles must just rest on the
ground. Setting the contact pressure too
high does not produce better cleaning
results, it increases wear and reduces
the battery running time.
Guide Roller
The guide roller makes it easier to
control the sweeper along edges, e.g.
next to walls or curbs.
Hold-Down Device
The hold-down device can be pushed
down to keep the bristles close to the
ground when sweeping along edges,
e.g. next to walls or curbs.
N Push down knob on hold-down
device.
Thermal Overload Cutout
The thermal overload cutout interrupts
the power supply if the motors are
overloaded, e.g. if a side broom or roller
brush is blocked.
Switching On
9933BA009 KN
1
9933BA010 KN
Working
Setting Application
1 - 2 for flat surfaces
3 - 4 damp leaves, sand, uneven
surfaces, e.g. exposed
aggregate concrete
5 - 8 Readjustment to compen-
sate for bristle wear
9933BA011 KN
9933BA012 KN
9933BA013 KN
