Entel HX402S [7/26] Optional accessories
![Entel HX422S [7/26] Optional accessories](/views2/1076584/page7/bg7.png)
Attaching / Removing The Battery Pack
1 To attach, locate the pegs on the bottom of
the battery and place into the slots on the
radio. Then press the top of the battery
against the radio until you hear a click.
2 To remove, slide the two latches on the side
of the battery down and pull the battery away from the
top of the radio.
Attaching / Removing The Belt Clip
1 To attach, press the clip into the slot on the back of the
battery and slide down until you hear a “click”.
2 To remove, pull the tab (a) towards the belt clip. Then
slide the belt clip upwards (b).
Antenna Options
CXW400 Antenna adapter for external aerial connection
CAT420 Helical antenna VHF
CAT480 Whip antenna UHF
CAT480S Stubby antenna UHF
CAT410S-78 78MHz compressed antenna
CAT410S-85 85MHz compressed antenna
CAT410S 66-88MHz uncut compressed antenna
CAT400-40 30-50MHz antenna
6
Optional Accessories cont...
For complete up to date list of optional accessories visit www.entel.co.uk
12
1
2
Common
b
Preparing Your Radio For Use
a
