3 EN
Place the appliance on the fl oor or at a 45°
angle, since it is necessary to work on the
bottom of the appliance.
REVERSING THE OPENING OF THE DOORS
Remove the bottom right-hand hinge by
loosening the screws, then remove the door.
Remove the right-hand Bush and the left-
hand caps of the freezer door, both at the top
and at the bottom and reverse the position.
Remove the right-hand cap (A), left-hand cap
(B) and middle cap (C) from the Storm Door
in the fastening with cutting screwdriver in
the slot provided at the bottom.
Unscrew the central hinge and remove the
top door.
Unscrew the stopper of the fridge door and
mount the one provided on the other side.
Remove the cap from the left-hand side and
mount it on the right-hand side of the Storm
Door.
Unscrew the pin and the joint hinge.Remove the caps (D) and (E), remove the
screws and partially take out the panel.
Screw the pin and the joint hinge by using
the bottom holes.
Fasten the panel.
Insert the cap (E) and remount the caps on
the panel (right-hand side).
Remount the hinges and the doors by
working from bottom to top 1 2 3.
Insert the caps (A) and (B) in the fastening
and fi x the cap (C) by mounting it from the
cap (B) to the cap (A).
Replace the Appliance in a vertical position
and wait 2 hours before operating it again.
To reverse the handles: remove the outer
caps from the right-hand side of the doors.
Unscrew the handles from the left-hand
side.
Remount the handles on the right-hand
side.
Position the caps on the left-hand side of the
doors.
2 Hours
(A)
(C)
(B)
(A)
(B)
(C)
45°
E
D
1
2
3
