23 / 31 EN
Refrigerator / User Manual
Operating the product
Never leave the vegetables in their plastic bags in
the crisper. If they are left in their plastic bags, this
will cause them to rot in a little while. If you not
prefer the vegetable to get in contact with other
vegetables for hygienic reasons, use perforated
paper or a similar material instead of plastic bags.
Do not place pears, apricots, peaches etc.,
especially those fruits that generate large amounts
of ethylene, in the same crisper with other fruits
and vegetables. The ethylene gas emitted by these
fruits cause other fruits to ripen sooner and to rot
in a shorter span of time.
5.11 Egg tray
You can install the egg holder to the desired door
or body shelf.
Never keep the egg holder in the freezer
compartment.
3-Movable middle section is closed when the left
door of the fridge compartment is opened.
4-It must not be opened manually. It moves under
the guidance of the plastic part on the body while
the door is closed.
5.13 Cool Control Storage
Compartment
The Cool Control Storage Compartment of your
refrigerator may be used in any desired mode
by adjusting it to fridge (2/4/6/8 °C) or freezer
(-18/-20/-22/-24) temperatures. You can keep the
compartment at the desired temperature with the
Cool Control Storage Compartment's Temperature
Setting Button. The temperature of the Cool
Control Storage Compartment may be set to 0 and
10 degrees in addition to the fridge compartment
temperatures and to -6 degrees in addition to
the freezer compartment temperatures. 0 degree
is used to store the deli products longer, and -6
degrees is used to keep the meats up to 2 weeks
in an easily sliceable condition.
The feature of switching to a Fridge or Freezer
compartment is provided by a cooling element
located in the closed section (Compressor
Compartment) behind the refrigerator. During
operation of this element, sounds similar to the
sound of seconds heard from an analogue clock
may be heard. This is normal and is not fault
cause.
5.14 Blue light
(in some models)
Crisper of the refrigerator are illuminated with a
blue light. Foodstuff stored in the crisper continue
their photosynthesis by means of the wavelength
effect of blue light and thus, preserve their
freshness and increase their vitamin content.
5.15 Odour filter
Odour filter in the air duct of the fridge
compartment prevents build-up of unpleasant
odours in the refrigerator.
5.12 Movable Middle Section
Movable middle section is intended to prevent
the cold air inside your refrigerator from escaping
outside.
1- Sealing is provided when the gaskets on the
door presses on the surface of the movable middle
section while the fridge compartment doors are
closed.
2- Another reason that your refrigerator is
equipped with a movable middle section is that it
increases the net volume of the fridge compart-
ment. Standard middle sections occupy some
non-usable volume in the refrigerator.
