• Split - Sky Air • Indoor Unit 3
• Indoor Unit • 4-way blow ceiling suspended unit • FUQ-C
2 Specifications
2-1 Technical Specifications FUQ71C FUQ100C FU Q125C
Power input - 50Hz Cooling Nom. kW 0.109 0.163 0.185
Heating Nom. kW 0.103 0.158 0.180
Casing Colour Fresh White
Material Resin
Dimensions Unit Height/Width/
Depth
mm 198/950/950
Packed unit Height/Width/
Depth
mm 295/1,026/1,016
Weight Unit kg 25 26
Packed unit kg 36 38
Packing Material Carton / OSB board Carton / OSB board Carton / OSB board
Weight kg 8.3
Heat exchanger Inside length mm 2,413 2,360
Length mm - 2,413
Outside length mm 2,467
Rows Quantity 2 3
Fin pitch mm 1.2
Face area m² 0.3380 0.3300
Stages Quantity 10
Empty tubeplate
hole
Quantity 0
Tube type Hi-XA
Tube material Copper
Tube diameter mm 5.0
Fin Type Multi slit fin
Treatment Anti Corrosion Hydrophilic
Fan Type Turbo fan
Quantity 1
Air flow rate Cooling High m³/min 23 31 32.5
cfm 812 1,095 1,148
Nom. m³/min 19.5 25.5 26.5
cfm 689 901 936
Low m³/min 16 20 20.5
cfm 565 706 724
Heating High m³/min 23 31 32.5
cfm 812 1,095 1,148
Nom. m³/min 19.5 25.5 26.5
cfm 689 901 936
Low m³/min 16 20 20.5
cfm 565 706 724
Fan motor Quantity 1
Model ARW5203DK EHDS10DDK
Index of Protection 20
Insulation grade Class "E"
Poles 8
Drive Direct drive
Speed Steps 3
Cooling High/
Mediu
m/Low
rpm 608/528/448 804/680/555 840/697/555
Heating High/
Mediu
m/Low
rpm 608/528/448 804/680/555 840/697/555
Output High W 46 106
Phase x Voltage V DC280V
Fu ll l oa d amps
(FLA)
Cooling A 0.7 1.0 1.1
Heating A 0.7 1.0 1.1
Sound power level Cooling High/Nom./Low dBA 59/56/51 64/60/55 65/61/56
Heating High/Nom./Low dBA 59/56/51 64/60/55 65/61/56
