• Indoor Unit • 4-way blow ceiling suspended unit • FUQ-C

• Split - Sky Air • Indoor Unit4

2 Specifications

Standard Accessories : Drain hose;

Standard Accessories : Declaration of conformity;

Standard Accessories : Operation manual;

Standard Accessories : Installation manual;

Standard Accessories : Clamp metal;

Standard Accessories : Washer for hanger bracket;

Standard Accessories : Clamps;

Standard Accessories : Washer clamp;

Standard Accessories : Joint insulation & Sealing material;

Standard Accessories : Elbow;

Standard Accessories : Installation pattern;

Standard Accessories : Blocking material;

Standard Accessories : L-bent piping;

Standard Accessories : Screws;

Standard Accessories : Non woven fabric;

Sound pressure level Cooling High/Nom./Low dBA 41/38/35 46/42/39 47/43/40

Heating Super high/High/

Nom./Low

dBA -/41/38/35 -/46/42/39 -/47/43/40

Refr ig eran t Typ e R-410A

Piping connections Sound absorbing insulation Not needed

Liquid Type/OD mm C1220T (Flare connection)/9.52

Gas Type/OD mm C1220T (Flare connection)/15.9

Drain VP25 (OD Ø32.0)

Heat insulation Needed

Air direction control Up and downwards

Air filter Type Resin net with mold resistance

Quantity pc 1

Drain-up height mm 600

2-2 Electrical Specifications FUQ71C FU Q100C FUQ125C

Power supply Name VE

Phase 1~

Frequency Hz 50/60

Voltage V 220-240/220

Current - 50Hz Maximum running current A 0.9 1.3 1.4

Current - 60Hz Nominal running current A -

2-1 Technical Specifications FUQ71C FU Q100C FUQ125C
