Vitek VT-3453 [5/28] Qxd 24 5 5 15 00 page 5
![Vitek VT-3453 [5/28] Qxd 24 5 5 15 00 page 5](/views2/1007668/page5/bg5.png)
CONTROL BUTTONS
Front and Rear Panels
1. VOLUME buttons
- for setting the volume level
2. Function selector
- to choose the audio source: MP3/CD, TAPE
or RADIO, and also to turn off the power.
3. Headphones jack
- 3.5 mm jack for stereo headphones
4. CD compartment lid
5. Cassette deck control buttons
PAUSE (
;;
)
- temporarily stops recording and playback.
STOP/EJECT ( )
-stops playback/recording
-opens the cassette deck
F.FWD (
88
) - fast forward
F.REW(
77
) - fast rewind
PLAY(
44
) - begin playback
RECORD ( )- begin recording
6. Cassette deck cover
press the stop/open button to open/close the deck
7. Radio band selector (FM ST FM AM)
- for choosing the radio band (FM ST./FM/AM)
8. TUNING dial
- for tuning FM/AM radio frequencies
9. BACK button (9)
-to return to the beginning of the previous track.
10. PLAY/PAUSE (
44;;
) button
- start/pause playback of a CD/MP3 disc
11. NEXT button (
:
)
- skip to the beginning of the next track
12. STOP ( )button
-for stopping MP3/CD playback
13. PROG. button
- for programming playback of CD/MP3 tracks
14. FOLDER DN button
- to move one folder/album down
15. FOLDER UP button
- to move one folder/album up
16. LCD display
- shows information regarding the CD/MP3 disc playback
17. OPEN button
- for opening the CD compartment lid
18. Battery compartment
19. Power cord jack
20. Radio tuning scale
21. FM antenna
22. Speakers
23. Carrying handle
24. Built in microphone
Power Supply
Using AC Power
1. Check if the power voltage, as shown on the type plate
located on the bottom of the set, corresponds to your
local AC power supply. If it does not, consult your dealer
or service centre.
2. Connect the power cord to the AC MAINS inlet and the
wall outlet. The power supply is now connected and
ready for use.
3. To switch off completely, unplug the power cord from the
wall outlet.
=
Unplug the power cord from the wall outlet to protect
your set during heavy thunderstorms.
Batteries (not included)
Open the battery compartment and insert eight batteries,
type R-14, UM-2 or C-cells, (preferably Alkaline) with the
correct polarity as indicated by the "+" and "-" symbols
inside the compartment.
Batteries contains chemical substances, so they
should be disposed of properly.
Incorrect use of batteries can cause electrolyte leakage and
will corrode the compartment or cause the batteries to burst.
Therefore:
=
Do not mix battery types: e.g. alkaline with carbon Zinc.
Only use batteries of the same type for the set.
=
When inserting new batteries, do not try to mix old bat-
teries with new ones.
=
Remove the batteries if the set is not be used for a long
time.
ENGLISH
5
3453.qxd 24.05.05 15:00 Page 5
