3) Remove the lower hinge (and relative washers), by loosening screws A as shown in

the figure.

4) Remove the lower door.

5) Remove the middle hinge (and relative washers), by loosening screws B as shown in

the figure 3. Models with the upper tall door (fig. 3c – inside upper portion of the top door),

before removing screws that fix the central hinge (between fridge and freezer door) open

the top door and remove cap M and plastic insert L. When reversing the doors, the doors

need to be supported at all times.

6) Remove the top door. Remove screw N from the right bottom hinge (fig 3d – bottom

section of the appliance with kickplate removed). Take the left bottom hinge from the pla-

stic bag and fix it to the bottom of the appliance with the screw you removed from the

right bottom hinge.

7) Remove the plastic film, covering the upper left-hand hinge, from the facing.

8) Unscrew journal C from the upper right-hand hinge and refit it on the left. Models with

the upper tall door (fig. 3b – inside upper portion of the top door ), remove caps F-G, pivot

D and the right upper hinge, taking away the screw. Take the left upper hinge (H) from

plastic bag and fix it with the screw you have removed. Fix pivot D with washer to the left

upper hinge. After transferring the hinge to the left hand side, the plastic insert (L) which

covers this mechanism needs to be altered, the membrane of cap G needs to be broken

so that its fits back into place.

9) Replace the doors working in a reverse fashion (6-5-4-3-2); remembering to refit the

spacing washers between door and hinge.

10) Move the vertical handles, if they have been supplied, from the left hand side to the

right hand side, by adjusting the relevant screws. For handles marked “M”, move them

diagonally across from left to right. Remove the adhesive label from the left handle, take a

new label from the accessory pack, remove the protective strip and attach it to the right

handle.

11) Restore the appliance to an upright position.

N.B. Correct alignment of the doors is obtained by adjustment of the middle hinge.

REVERSING THE OPENING OF THE DOORS (see fig. 7)

To reverse the appliance doors, please contact GIAS SERVICE (tel. 08705 990011) to

arrange an appointment with an engineer, who will provide this service for a nominal

charge.

For models with a bottom hinge both on the right and the left.

1) We recommend that the refrigerator be tilted about 45 degrees.

2) Remove the screws (A) that hold the central hinge in place.

3) Remove the top door.

4) Remove the central hinge.

5) Remove the bottom door.

6) Remove the pin (B) from the bottom right hinge and reassemble on the left.

7) Remove the plastic membrane covering the top left hinge from the panel.

8) Remove the pin (C) from the top right hinge and reassemble it on the left.

9) Refit the doors in the reverse order (5-4-3-2) and remember to also fit the spacer

washers, if they are available.

10) Move the vertical handles, if they have been supplied, from the left hand side to the
