FITTING THE APPLIANCE INTO COLUMN CABINETS

Double doors and combis

The built-in dimensions are shown in fig. 14/15.

Proceed as follows to fit the appliance:

- Fit gasket 1 (provided with the appliance) to the side opposite the hinges (fig. 5).

- Fit the appliance into the column cabinet, setting it flush to the side without hinges and

push backwards so that a distance of 45 mm. is achieved between the appliance and the

front of the cabinet (fig. 6).

- Fix the appliance firmly at the top and bottom with the screws provided in the accesso-

ries pack and snap fit the ventilation grid into position (fig. 7).

Furthermore, for those models with lateral fixing clamps, proceed as follows (fig. 8):

- Centre hinge side - slacken off hinge fixing screw 1 and offer up clamp 3 to the column.

- Opposite side from the centre hinge - remove the clamp cover 2 and offer up the clamp

to the column.

- Screw the clamps to the column using the screws to be found in the accessory pack and

tighten the screws lackened off previously.

- Refit the clamp cover.

HOW TO COUPLE THE DOORS OF THE APPLIANCE

WITH THOSE OF THE COLUMN CABINET

The appliance is fitted with devices to couple its doors with those of the column cabinet

(dragging slides). The slides should be fitted as follows:

- (Fig. 9) Fix slide 1 to the door of the cabinet at the desired height and at approximately

20 mm. from the side edge of the door.

- (Fig. 10) Open the cabinet and refrigerator doors and fit the coupling device 2 onto slide 1.

- Keep the coupling 2 aligned with the refrigerator door.

- Mark the drilling points for the screws and drill 2,5 diameter holes.

- The slots in the coupling 2 facilitate easy adjustment.

- It is recommended that the dragging slides are fitted to the appliance door in correspon-

dence with the column door handles.

Furthermore with models fitted with extra handles for opening the door, proceed as fol-

lows (fig. 11):

- Offer up handle 1 to the door, then drill a hole corresponding to the one on the handle.

- Screw home using the screws in the accessory pack.

ADVICE FOR PROPER OPERATION

To obtain the maximun efficiency from your appliance it is important to allow good

ventilation to the system in order to cool down the condenser positioned at the

rear of the appliance.

DOUBLE DOOR COMBI AND SINGLE DOORS

To this end an opening must be made in the bottom of the column for an air inlet

(fig. 13). For the air outlet the column should be equipped with an upwards direc-

ted, unobstructed rear vent.

Should the column be flush fitted to the ceiling, such an outlet should be present

between it and the ceiling (fig. 13).

The appliance should not be installed in areas where the temperature remains belows

+16°C or above +32°C for long periods.
