FULLY BUILT IN REFRIGERATION

FITTING INSTRUCTIONS

MODELS FOR UNDER-COUNTER FITTING

REVERSING THE OPENING OF THE DOORS

This appliance is designed so that the opening of the doors can be reversed. To achieve

this proceed as follows:

SINGLE DOOR

REVERSING THE DOOR

(fig. 1)

- Remove hinge pin 1 and hinge bush from top rail.

- Remove the door.

- Remove journal 3 (and the relative washers) from the lower right-hand hinge and refit it

to the lower left-hand hinge.

REVERSING THE LOW TEMPERATURE COMPARTMENT DOOR (fig. 4)

In models with freezer compartments, in order to reverse the door, proceed as follows:

(fig.4a):

- Open door 1 to about 90°.

- Remove coupling 2.

- Remove hinge 3 together with door 1.

- Turn the three items 180° and refit everything by reversing the procedure.

(fig.4b):

- Open the door to 90 degrees.

- Remove the bracket 2.

- Remove the lower hinge 3.

Turn the door (1) round by 180 degrees and fix the bracket (2) on to the opposite

side.

Two door refrigerator (fig. 2):

- Remove upper hinge 1 and journal 2 (and the relative washers).

- Remove the upper door.

- Remove central hinge 3 (and the relative washers).

- Remove the lower door.

- Remove journal 4 (and the relative washers) from the lower right-hinge and refit to the

lower left-hand hinge.

- Reverse screws 7, screw cover plugs 6 and hole cover plugs 5 on the unit.

- Furthermore, with models fitted with side fixing clamps, instead of the hole cover plugs

5, reverse the clamp covers (fig. 3) which are fly-fitted on the clamp.

Combi (fig. 3):

- Remove hinge pin 1 and hinge bush from top rail.

- Remove the upper door.

- Remove the centre hinge 2 (and the relative washers).

- Remove the lower door.

- Remove journal 3 (and the relative washers) form the lower right-hand hinge and refit it

to the lower left-hand hinge.

- Reverse the fly-fitted clamp cover 4, mounted on the clamp.
