• Split - Sky Air • RXS-L3
9
• Outdoor Unit • RXS-L3
2 Specifications
Notes
(1) Nominal efficiency: cooling at 35°/27° nominal load, heating at 7°/20° nominal load
(2) 220V
(3) 230V
(4) 240V
(5) EER/COP according to Eurovent 2012, for use outside EU only
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Nominal efficiency: cooling at 35°/27° nominal load, heating at 7°/20° nominal load
Seasonal efficiency
(according to
EN14825)
Cooling Energy label B
Pdesign kW 3.50
SEER 4.87
Annual energy
consumption
kWh 252
Heating (Average
climate)
Energy label A
Pdesign kW 2.90
SCOP/A 3.80
Annual energy
consumption
kWh 1,068
Piping connections Liquid OD mm 6.35
Gas OD mm 9.5
Drain OD mm 18.0
Heat insulation Both liquid and gas pipes
Current Nominal running
current (RLA) - 50Hz
Cooling A 5.70 (2) / 5.49 (3) / 5.27 (4)
Heating A 5.60 (2) / 5.30 (3) / 5.10 (4)
Nominal efficiency EER 2.88 (5)
COP 3.57 (5)
Annual energy consumption kWh 608
Energy label Cooling B
Heating A
2-8 Capacity and Power input FNQ25A/RXS25L3 FNQ35A/RXS35L3
Cooling capacity Nom. kW 2.6 3.4
Heating capacity Nom. kW 3.20 4.00
Power input Cooling Nom. kW 0.69 1.11
Heating Nom. kW 0.80 1.15
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+
Pdesign kW 2.60 3.40
SEER 5.63 5.65
Annual energy
consumption
kWh 162 211
Heating (Average
climate)
Energy label A+
Pdesign kW 2.80 2.90
SCOP/A 4.24 4.05
Annual energy
consumption
kWh 925 1,002
Nominal efficiency EER 3.77 (1) 3.06 (1)
COP 4.00 (1) 3.48 (1)
Annual energy consumption kWh 345 556
Energy label Cooling A B
Heating A B
