1-6

Chapter 1: Intel

RAID Configuration

1.1.3 Intel

Rapid Storage Technology in UEFI BIOS

To enter the Intel

Rapid Storage Technology in UEFI BIOS:

1. Enter the BIOS Setup during POST.

Refer to Chapter 3 in your motherboard’s user manual for details on entering and

navigating through the BIOS Setup.

2. Go to Advanced > PCH Storage Configuration, then set SATA Mode Selection to

[Intel RST Premium With Intel Optane System Acceleration (RAID)].

Due to chipset limitation, when SATA ports are set to RAID mode, all SATA ports run at

RAID mode together.

3. Configure additional settings for your storage device and RAID configuration:

• If you are using SATA storage devices, no additional settings are required.

Please proceed to next step.

• If you are using onboard M.2 cards, go to Advanced > PCH Storage

Configuration, then set all the corresponding M.2 PCIE Storage RAID Support

to [Enabled].

• If you are using Hyper M.2 cards or PCIE SSDs, go to Advanced > CPU

Storage Configuration, then set all the corresponding PCIE slots to [Hyper M.2

X16] or [PCIE X4 SSD Card] accordingly.

The Hyper M.2 card is purchased separately.

4. Go to Boot > CSM (Compatibility Support Module), then set Launch CSM to

[Disabled].

5. Save your changes and exit the BIOS Setup, then enter the BIOS Setup again.

6. Go to the Advanced > Intel(R) Rapid Storage Technology to display the Intel

Rapid Storage Technology menu.
