![Asus PRIME Z490-A [31/68] Max cpu cache ratio](/views2/1769276/page31/bg1f.png)
PRIME/PRO/ProArt/TUF GAMING Intel 400 Series BIOS Manual
31
TVB Ratio Clipping
This service controls Core frequency reduction caused by high package temperatures
for processors that implement the Intel Thermal Velocity Boost (TVB) feature. It is
required to be disabled for supporting overclocking at frequencies higher than the
default max turbo frequency. Uses Overclocking Mailbox command 0x18/0x19.
Configuration options: [Auto] [Enabled] [Disabled]
Tweaker’s Paradise
Realtime Memory Timing
This item allows you to enable or disable realtime memory timing.
Configuration options: [Enabled] [Disabled]
FCLK Frequency for Early Power On
This item allows you to set the FCLK Frequency for Early Power On.
Configuration options: [Auto] [Normal (800 MHz)] [1GHz] [400 MHz]
1 GHz is not supported for ULT/ULX SKUs.
DRAM VTT Voltage
Configuration options: [Auto] [0.500] - [1.300]
VPPDDR Voltage
Configuration options: [Auto] [1.865] - [3.135]
Internal PLL Voltage
Configuration options: [Auto] [0.900] - [1.845]
GT PLL Voltage
Configuration options: [Auto] [0.900] - [1.845]
Ring PLL Voltage
Configuration options: [Auto] [0.900] - [1.845]
System Agent PLL Voltage
Configuration options: [Auto] [0.900] - [1.845]
Memory Controller PLL Voltage
Configuration options: [Auto] [0.900] - [1.845]
CPU Standby Voltage
Configuration options: [Auto] [0.800] - [1.800]
Min. CPU Cache Ratio
This item allows you to set the minimum possible CPU cache ratio. Use the <+> and <->
keys to adjust the value.
Configuration options: [Auto] [8] - [44]
Max. CPU Cache Ratio
This item allows you to set the maximum possible CPU cache ratio. Use the <+> and <->
keys to adjust the value.
Configuration options: [Auto] [8] - [44]
