![Asus Pro WS W480-ACE [128/196] You can scan for client devices which support the management control functions by clicking on scan clicking on a device from the scan results will redirect you to the ma...](/views2/1769475/page128/bg80.png)
5-40 Chapter 5: Management Functions
5.4 Management Control Overview
The Management Control options allow you to manage a client device remotely
which is connected via a management LAN port which supports RTL8117 LAN IC,
and also allows out-of-band management.
• Ensure the client device’s RTL8117 is enabled if it uses RTL8117 for
remote management control, and this is a new machine which is used for
the first time or has been reset to factory settings. In the device’s BIOS,
navigate to
Advanced
>
RTL8117
setting
, then enable RTL8117.
• If an agent has already been deployed to the device, you can also enable
RTL8117 through the BIOS function. Please refer to
4.10.2 BIOS Setting
.
To access
Management Control
, click on located at the top right menu bar.
5.4.1 Scanning for devices
You can scan for client devices which support the Management Control functions
by clicking on
Scan
. Clicking on a device from the scan results will redirect you to
the
Management Control Information
page.
