1-2 Chapter 1: Getting Started
1.1 Setting up
1.1.1 Installing ASUS Control Center Express (ACCE)
1. Please visit the product website of your ASUS product to download the ASUS
Control Center Express installer.
1. Unzip the installation file then execute Setup.exe. You should be guided to
install vcredist_x64, vcredist_x86, and ASUS Control Express respectively.
• If there is an older version of ASUS Control Center Express already
installed on your system and you wish to clear the original configurations of
the older version, you may check the
Clear original configuration
option
during the installation process to remove the configuration settings of the
older version of ASUS Control Center Express.
• We DO NOT recommend clearing the configuration settings of older
versions of ASUS Control Center Express unless necessary.
