Asus ROG MAXIMUS XIII HERO [53/90] Chapter 2

ROG MAXIMUS XIII HERO

2-11

Chapter 2

10. Remove the plastic film from the thermal pads on the bottom of the heatsink.

11. Replace the heatsink.

12. Secure the heatsink using the screws removed previously.
