Asus ROG STRIX Z390-F GAMING [53/96] Asus fan holder installation

ROG STRIX Z390-F GAMING

2-13

Chapter 2

2.1.10 ASUS fan holder installation

To install the ASUS fan holder and fan

Whenusinghighperformancesettingswhilstoverclocking,ensuretoinstallthefanholder

foradditionalfan(s).

• Youmayinstall12V(1A,12W),40mmx40mmfansor50mmx50mmfans.

• Ensuretotheusethebundledscrewsthatcamewithyourfans.

• Fansarepurchasedseparately.
