ROG STRIX H370-F GAMING BIOS Manual
39
1.6.5 PCH Storage Configuration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Empty if no SATA device is installed to the corresponding SATA port.
Scroll down to display the other BIOS items.
1.6.4 PCH Configuration
The items in this menu allow you to adjust the PCH PCI Express speed.
PCI Express Configuration
This item allows you to congure the PCI Express slots.
PCIe Speed
This item allows your system to automatically select the PCI Express port speed.
Conguration options: [Auto] [Gen1] [Gen2] [Gen3]
IOAPIC 24-119 Entries
Allows you to enable or disable IOAPIC 24-119 Entries. IRQ24-119 may be used by PCH
devices. Disabling those interrupts may cause certain device failures.
Conguration options: [Disabled] [Enabled]
