Asus ROG MAXIMUS XI GENE [10/110] Rog maximus xi gene specifications summary

(continued on the next page)

LAN

Intel

I219-V Gigabit LAN- Dual interconnect between the integrated

Media Access Controller (MAC) and physical layer (PHY)

Anti-surge LANGuard

Wireless & Bluetooth

Intel

Wireless-AC 9560

2 x 2 Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac supports dual

frequency band 2.4/5 GHz

Supports channel bandwidth: HT20/HT40/HT80/HT160. Up to

1.73Gbps transfer speed

Bluetooth v5.0

Audio

ROG SupremeFX S1220A Codec

- Supports up to 32-Bit/192kHz playback*

- Impedance sense for front and rear headphone outputs

- Jack-detection, Multi-streaming, and Front Panel Jack-retasking

- Optical S/PDIF out port at back panel

* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for

8-Channel audio.

USB

Intel

Z390 Express Chipset

- 1 x USB 3.1 Gen 2 Type-C™ front panel connector

- 4 x USB 3.1 Gen 2 ports (3 x Type-A and 1 x Type-C™)

- 8 x USB 3.1 Gen 1 ports ( 2 ports at mid-board [grey])

- 4 x USB 2.0 ports (4 ports at mid-board [black])

ROG MAXIMUS XI GENE specifications summary
