Accessory
Kit Contents
配備零組件內容物 | 配备组件内容物 | Obsah sady příslušenství | Contenu du kit d'accessoires |
Verpackungsinhalt des Zubehörsatzes | Accessori contenuti nel kit | アクセサリキットの内容 | 액세서리
키트 내용물 | Zawartość zestawu akcesoriów | Conteúdo do kit de acessórios | Содержимое комплекта |
Contenido del kit de accesorios | Tillbehörssatsens innehåll | Aksesuar Kitinin İçindekiler | Obsah súpravy s
príslušenstvom |
Cable Ties
x10
USB Type A(3.0) Dust Cover
x2
USB Type C(3.1) Dust Cover
x1
Motherboard Standos
x3
Stando Tool
x1
Motherboard / 2.5” Drive Screws
x40
x1
Pump Bracket
x1
Vertical GPU Kit
x1
PSU Screws
x4
A
B
C
D
E
F
G
H
I
J
2
Pump Bracket Captive Thumb Screws
(Note: the pump bracket screw is included on the pump bracket)
