Entel RP520 [6/13] Preparing the base station for use

Before use check the following:

The external antenna connection is correctly fitted to the base station before it is switched on.

Dependent upon configuration either one or both ‘N Type’ sockets may be used. Check with

your dealer.

The antenna plug must be screwed fully on to the socket. Failure to attach the antenna correctly

can lead to poor performance and damage the unit.

Turn the base station on/off

When powered from the mains, use the rear mounted isolator switch to power the base.

To turn the base on/off turn the front mounted on/off volume control clockwise.

Receiving calls on the base station

Calls can be monitored on the base station utilising the internal loudspeaker. Use the on/off

volume control to set a comfortable listening volume.

Attaching / Removing an optional local control microphone

Calls can be made from the base station using one of the Entel approved microphone options.

To insert the optional local control microphone, ensure that the plug with the locking nib is

uppermost and push the plug in to the socket until it clicks in to place. To remove the plug, push

down the nib on the plug and pull out.

Talk Through enable/disable

Talk Through facility can be enabled or disabled from the front of the base station. To enable

press the talk through button and the LED will illuminate to show the feature is active. To disable

press the talk through button again (the LED will extinguish)

Common

Nib

Preparing the base station for use
