Daikin SB.RKXYQ8T [7/27] Specifications

• VRV Systems • SB.RKXYQ-T

• Outdoor Unit • SB.RKXYQ-T

2 Specifications

Refrigerant oil Type Synthetic (ether) oil

Charged volume l 1.75 -

Piping connections Drain OD mm - 32

2-4 Electrical Specifications RKXYQ5T RDXYQ5T

Power supply Name Y1 V1

Phase 3N~ 1N~

Frequency Hz 50

Voltage V 380-415 220-240

Voltage range Min. % -10

Max. % 10

Current Nominal running

current (RLA) - 50Hz

Cooling A 5.8 1.8

Current - 50Hz Minimum circuit amps (MCA) A 13.5 4.6

Maximum fuse amps (MFA) A 16 10

Total overcurrent amps (TOCA) A 13.5 4.6

Full load amps

(FLA)

Fan motor A - 2.2

Fan motor 2 A - 2.2

Wiring connections -

50Hz

For power supply Quantity 5G 3G

2-3 Technical Specifications RKXYQ5T RDXYQ5T
