Hardware Features Connectivity Options
Connecting digital speaker systems (Home Theater)
Connecting 2 channel speakers
Connecting analog power amplier
Connecting 4 channel speakers
Connecting microphone
Connecting 5.1 channel speakers
Connecting Line-In audio sources
Connecting stereo headphones
Connecting 5.1 channel headphones
No Item Description
1 Front Out/
Headphone Jack
TheFrontOutjackhasabuilt-inhigh-qualityamplier
to drive headphones. Connect your stereo headphones
directlytothisjack.
No Item Description
1 Front Out/
Headphone Jack
Connectthe2speakerset’s3.5mmplugintothisFrontOut
jack.
No Item Description
1 Front Out port Connects to the Front input port of the 4 speakers
withthemini-jackcable.
2 Side Surround Out
port
ConnectstotheSurroundinputportofthe4
speakerswiththemini-jackcable.
No Item Description
1 Microphone Input
Jack
Connectthemicrophone’s3.5mmplugintothis
Mic-Injackforvoicecommunication,recording,or
karaoke.
2 Headphone Jack TheFrontOutjackhasabuilt-inhigh-quality
amplier to drive headphones. Connect your stereo
headphonesdirectlytothisjack.
No Item Description
1 Front Out port Connects to the Front input port of the 5.1 speakers
withthemini-jackcable.
2 Side Surround Out
port
ConnectstotheSurroundinputportofthe5.1
speakerswiththemini-jackcable.
3 Center/Subwoofer
Out port
ConnectstotheCenter/Subwooferinputportofthe
5.1speakerswiththemini-jackcable.
No Item Description
1 Line Input Jack Connectthe3.5mmplugoftheCD/MP3Playerorany
otherLinelevelanalogaudiosourcesintothisLine-In
jackforsoundrecording(Seethe“Mixer”sectionof
the driver guide).
No Item Description
1 Optical cable Plugyourdecoder’sTOSLINKopticalcableintotheS/
PDIF-Outconnector.
1
SPDIF Out
1
1
2
3
No Item Description
1 Front Out port Connectthefront-channel3.5mmplugofyour5.1
channelheadphoneintothisjack.
2 Side Surround Out
port
Connectthesurround-channel3.5mmplugofyour
5.1headphoneintothisjack.
3 Center/Subwoofer Out
port
ConnecttheCenter/Bass-channel3.5mmplugofyour
5.1headphoneintothisjack.
1
2
3
No Item Description
1 Front Out port Connectstothe“leftfront”and“rightfront”inputports
oftheanalogamplierwiththemini-jacktoRCAcable.
2 Side Surround Out
port
Connectstothe“leftsurround”and“rightsurround”
inputportsoftheanalogamplierwiththemini-jackto
RCAcable.
3 Center/Subwoofer Out
port
Connectstothe“Center”and“subwoofer”inputportsof
theanalogamplierwiththemini-jacktoRCAcable.
1
2 Speakers
4 Speakers
1
2
1
2
3
Mic In
1
2
1
1
2
Headphone Out
Line In
1
