6 Chapter 1: Product introduction
ENGLISH
ENGLISH
ENGLISH
ENGLISH
Specications summary
ITEM DESCRIPTION
Audio Performance
Output Signal-to-Noise Ratio
(AWeighted)
124dB for Front-out
120dB for Headphone-out at 600ohms
Input Signal-to-Noise Ratio
(AWeighted)
118dB
Output Total Harmonic
Distortion + Noise
at 1kHz (-3dB) :
0.0003% (-110dB) for Front-out
0.001% (-100dB) for Headphone-out
Input Total Harmonic Distortion
+ Noise at 1kHz (-3dB)
0.0002% (-113dB) for Line-In
Frequency Response (-3dB, 24-
bit/96kHz format)
10Hz to 90KHz
Output/Input Full-Scale Voltage 2 Vrms (Line Out)
7 Vrms (Headphone Out)
Headphone Impedance Optimized for 32~600ohm
Main Chipset
Audio Processor ASUS AV100 High Denition Sound Processor
(Maximum 192KHz/24bit)
24-bit D-A Converter of Digital
Sources
Texas Instruments PCM1792A*1 for Front Out
(127dB SNR, 192kHz/24bit)
High Fidelity Headphone
Amplier
Texas Instruments 6120A2*1 (120dB SNR, 100dB
THD+N @ Vcc+- 12V, R
L
= 600ohms, f=1kHz)
24-bit A-D Converter for Analog
Inputs
Cirrus-Logic CS5381*1 (120dB SNR, Maximum
192kHz/24bit)
Sample Rate and Resolution
Analog Playback Sample Rate
and Resolution
44.1K/48K/96K/192kHz @ 16/24bit
Analog Recording Sample Rate
and Resolution
44.1K/48K/96K/192kHz @ 16/24bit
SPDIF Digital Output 44.1K/48K/96K/192kHz @ 16/24bit,
Dolby Digital
continued on the next page)
