9
HIGH PRESSURE WASHER
The cleaner can only be connected to the water
mains if the water mains is separated by a back-
flow preventer. Make sure that the hose is at least Ø
13mm-1/2 inch and that it is reinforced.
WARNING: Water that has flown through
backflow preventers is considered to be
nonpotable.
IMPORTANT: Only clean or filtered water should
be used for intake. The delivery of the water
intake tap should be equal to the double of the
maximum pump range.
- Minimum delivery rate: 15 l/ min.
- Maximum intake water temperature: 40°C
- Max inlet water pressure: 1Mpa
Place the cleaner as close to the water supply system
as possible.
Water supply from an open container
- Unscrew the coupling part for the water inlet.
- Screw the suction hose with filter (not included)
onto the water connection of the unit.
- Hang the filter in the container.
- Vent the unit before operation.
- Unscrew the high-pressure line at the high-
pressure outlet of the unit.
- Switch on the unit and let it run until water free of
bubbles emerges at the high-pressure outlet.
- Switch o the unit and screw on the high-pressure
hose again.
Failure to comply with
the above conditions causes
serious mechanical damage to the pump and the
loss of warranty cover.
> ELECTRICITY SUPPLY
- The appliance’s electrical connection must
comply with the IEC 60364-1 standard.
IMPORTANT: Before connecting the
appliance, make sure that the nameplate data are
the same as those of the electrical mains and that
the socket is protected by a dierential security
breaker with tripping sensitivity below 0.03 A - 30
ms.
- If t
he appliance’s plug is not compatible with the
socket, have the socket replaced with another of
suitable type by professionally qualified sta.
- Never use the appliance in ambient temperatures
below 0° C if it is equipped with a PVC (H VV-F)
cable.
XY WARNING: Inadequate extension cords can
be dangerous.
XJ WARNING: If an extension cord is used,
the plug and socket must be of watertight
construction.
Information for supply may also be obtained
from the plug manufacturer.
<16 A <25 A
<20 m ø 1,5 mm
2
- 14 AWG ø 2,5 mm
2
- 12 AWG
20 m - 50 m ø 2,5 mm
2
- 12 AWG ø 4,0 mm
2
- 10 AWG
> PLUG
HOW TO CONNECT THE CORD TO A U.K. PLUG:
IMPORTANT The wires in the mains lead are
coloured in accordance with the following code:
Blue Neutral
Brown Live
Yellow/Green Earth
Please read the instructions given below before con
-
necting the cord to a plug. If in doubt please consult
a qualified electrician. As the colours of the wires in
the mains lead of this applia
nce may not correspond
with the coloured markings identifying the termi-
nals in your plug, proceed as follows:
The wires that is coloured Brown must be connected
to the terminal which is marked with the letter L or
coloured Red. The wire that is coloured Blue must be
connected to the terminal which is marked with the
letter N or coloured Black.
Safety points for rewireable or moulded plug:
The mains lead of this appliance may be already
fitted with a
BS1363 13A plug.
- If your socket outlet is not suitable for the plug,
then the plug must be removed (cut oif it is a
moulded on plug), the flexible cord insulation
should be stripped back as appropriate and a
suitable 3 pin plug fitted.
WARNING: Dispose of
a plug that has been
cut from the power
supply cord, as such
a plug is hazardous
if inserted in a live
13A socket outlet
elsewhere in the
house.
- Should the fuse
need to be replaced
an ASTA marked fuse,
approved to BS1362, of the same rating must be
used.
- Always replace the fuse cover after fitting a fuse.
