Model No.DLM432 430MM CORDLESS LAWN MOWER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 326636-0 SWITCH LEVER 1

002 231876-6 TENSION SPRING 9 1

003 911138-5 PAN HEAD SCREW M4X20 2

004 455075-8 LEVER 1

005 455078-2 ARM 1

007 143510-5 UPPER PIPE COMPLETE 1

008 459804-1 SWITCH BOX 1

009 233068-3 COMPRESSION SPRING 6 1

010 455074-0 SWITCH BUTTON 1

011 650730-9 SWITCH TG72BD-6 1

012 687124-5 STRAIN RELIEF 1

013 265999-8 TAPPING SCREW 4X25 2

014 140N15-0

SWITCH BOX COVER

COMPLETE K

󳢢󳢢󳢢󳢢C10 890374-5 INDICATION LABEL 1

015 266326-2 TAPPING SCREW 4X18 4

016 266326-2 TAPPING SCREW 4X18 1

017 456352-1 SWITCH LEVER CASE COVER 1

018 456351-3 SWITCH LEVER CASE 1

019 326635-2 LOWER PIPE 1

020 265A14-4

CUP H. SQUARE NECK BOLT

M6X50

021 264070-5 THUMB NUT M6 2

024 266729-0 THUMB SCREW M8X35 2

026 459809-1 HOLDER 2

027 660393-3 POWER SUPPLY CORD 1

028 140N21-5

BATTERY COVER COMPLETE

󳢢󳢢󳢢󳢢C10 8005W1-7 CAUTION LABEL 1

029 890375-3 CAUTION LABEL 1

030 856L50-3 DLM432 NAME PLATE 1

031 856L57-9 DLM432 SERIAL NO. LABEL 1

032 8005W9-1 INDICATION LABEL 1

033 8005W4-1 INDICATION LABEL 1

034 8005W5-9 INDICATION LABEL 1

035 266459-3 TAPPING SCREW 5X25 2

036 273675-0 GRIP A 1

037 643890-4 KEY 1

038 266326-2 TAPPING SCREW 4X18 3

039 183N35-1 TERMINAL HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 4

󳢢󳢢󳢢󳢢D10 INC. 41

040 644809-6 TERMINAL 2

041 183N35-1 TERMINAL HOUSING SET 1

Please order the parts with part number. Print Date 26/3/2020
