RS+FCQ60B
Cooling capacity 230V [50Hz]
AFR 18
BF 0.10
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 5.8 4.5 1.84 5.6 4.4 1.94 5.5 4.3 2.03 5.4 4.3 2.07 5.3 4.3 2.13 5.2 4.2 2.22
16.0 22.0 5.9 4.5 1.87 5.8 4.4 1.96 5.6 4.4 2.06 5.6 4.4 2.10 5.5 4.3 2.15 5.3 4.2 2.25
18.0 25.0 6.1 4.6 1.89 5.9 4.5 1.99 5.8 4.4 2.08 5.7 4.4 2.12 5.6 4.3 2.18 5.5 4.3 2.27
19.0 27.0 6.2 4.6 1.91 6.0 4.5 2.00 5.9 4.4 2.10 5.8 4.4 2.13 5.7 4.4 2.19 5.6 4.3 2.29
22.0 30.0 6.4 4.6 1.95 6.2 4.6 2.04 6.1 4.5 2.14 6.0 4.5 2.17 5.9 4.4 2.23 5.8 4.3 2.33
24.0 32.0 6.5 4.7 1.97 4.7 4.6 2.07 6.2 4.5 2.16 6.2 4.5 2.20 6.1 4.4 2.26 5.9 4.4 2.35
3TW25082-1
RS+FFQ50B
Cooling capacity 230V [50Hz]
AFR 12.0
BF 0.16
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 4.76 3.51 1.45 4.61 3.44 1.55 4.46 3.37 1.64 4.40 3.34 1.68 4.31 3.30 1.74 4.16 3.23 1.83
16.0 22 4.92 3.54 1.48 4.77 3.47 1.57 4.62 3.40 1.67 4.56 3.38 1.70 4.47 3.33 1. 76 4.32 3.26 1.86
18.0 25 5.07 3.58 1.50 4.92 3.51 1.60 4.77 3.44 1.69 4.71 3.41 1.73 4.62 3.37 1.79 4.47 3.30 1.88
19.0 27 5.15 3.59 1.52 5.00 3.52 1.61 4.85 3.45 1.71 4.79 3.43 1.74 4.70 3.38 1.80 4.55 3.31 1.90
22.0 30 5.38 3.65 1.55 5.23 3.58 1.65 5.08 3.51 1.74 5.02 3.48 1.78 4.93 3.44 1.84 4.78 3.37 1.93
24.0 32 5.54 3.68 1.58 5.39 3.61 1.68 5.24 3.54 1.77 5.18 3.51 1.81 5.09 3.47 1.87 4.94 3.40 1.96
3D041021
RS+FFQ60B
Cooling capacity 230V [50Hz]
AFR 15.0
BF 0.11
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 5.86 4.30 1.72 5.71 4.23 1.82 5.56 4.16 1.91 5.50 4.13 1.95 5.41 4.09 2.01 5.26 4.02 2.10
16.0 22 6.02 4.34 1.75 5.87 4.27 1.84 5.72 4.20 1.94 5.66 4.17 1.97 5.57 4.13 2.03 5.42 4.06 2.13
18.0 25 6.17 4.37 1.77 6.02 4.30 1.87 5.87 4.23 1.96 5.81 4.20 2.00 5.72 4.16 2.06 5.57 4.09 2.15
19.0 27 6.25 4.39 1.79 6.10 4.32 1.88 5.95 4.25 1.98 5.89 4.22 2.01 5.80 4.18 2.07 5.65 4.11 2.17
22.0 30 6.48 4.44 1.82 6.33 4.37 1.92 6.18 4.30 2.01 6.12 4.27 2.05 6.03 4.23 2.11 5.88 4.16 2.20
24.0 32 6.64 4.47 1.85 6.49 4.40 1.95 6.34 4.33 2.04 6.28 4.30 2.08 6.19 4.26 2.14 6.04 4.19 2.23
3D041026
RS+FBQ50B
Cooling capacity 230V [50Hz]
AFR 14
BF 0.15
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 5.1 3.6 1.57 4.9 3.5 1.67 4.8 3.4 1.76 4.7 3.4 1.80 4.6 3.4 1.86 4.5 3.3 1.95
16.0 22.0 5.2 3.6 1.60 5.1 3.5 1.69 4.9 3.5 1.79 4.9 3.4 1.83 4.8 3.4 1.88 4.6 3.3 1.98
18.0 25.0 5.4 3.6 1.62 5.2 3.6 1.72 5.1 3.5 1.81 5.0 3.5 1.85 4.9 3.4 1.91 4.8 3.4 2.00
19.0 27.0 5.5 3.7 1.64 5.3 3.6 1.73 5.2 3.5 1.83 5.1 3.5 1.87 5.0 3.5 1.92 4.9 3.4 2.02
22.0 30.0 5.7 3.7 1.68 5.5 3.6 1.77 5.4 3.6 1.87 5.3 3.5 1.90 5.2 3.5 1.96 5.1 3.4 2.06
24.0 32.0 5.8 3.7 1.70 5.7 3.7 1.80 5.5 3.6 1.89 5.5 3.6 1.93 5.4 3.5 1.99 5.2 3.5 2.08
3TW25112-1
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat
2. Shows nominal cooling capacities and power input
3. TC, PI and SHC must be calculated by interpolation using the figures in the
above tables. (Figures out of the tables should not be used for calculation.)
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min) x (1-BF) x (DB-EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
6. Air flow rate (AFR) and Bypass factor (BF) are taburated above.
•
Pair Application •
R-410A •
RN20,25,35CVMB • RS50,60BVMB
3
Capacity tables
26
3
464
• Split - Sky Air • Outdoor Units
