ELECTRICAL DATA
RYN+FTYN20C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTYN20CVMB RYN20CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
14.0 15 42 2.81 25 0.35 18 0.20
3D044326
RYN+FTYN25C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTYN25CVMB RYN25CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
14.0 15 47 3.21 25 0.35 18 0.20
3D044327
RYN+FTYN35C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTYN35CVMB RYN35CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
14.0 15 70 4.41 25 0.35 18 0.20
3D044328
RYS+FTYS50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTYS50BVMB RYS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 72 6.92 53 0.18 40 0.16
3D040875
RYS+FTYS60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTYS60BVMB RYS60BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 72 8.86 53 0.24 43 0.16
3D040875
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency(Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
W : Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://www.daikineurope.com/extranet, select ’’Daikin
Documentation’’ and select ’’conditional connection’’, ’’the
requested product type’’ and ’’English’’ from the drop down
lists, click the search button.
Finally, click on the document title of your choice.
•
Pair Application • R-410A • RYN20,25,30CVMB • RYS50,60BVMB
