Indoor Unit SiENBE04-401A
166 Removal Procedure
1.7 Removal of Fan Rotor and Fan Motor
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
Remove heat exchanger.
1
To remove right side
plate, remove three
screws.
Right-side
plate
(R2557)
