Piping Diagrams SiENBE04-401A
222 Appendix
1. Piping Diagrams
1.1 Indoor Units
FTKS20/25/35CVMB(9)(8), ATKS20/25/35CVMB(9)
FTN20/25/35CVMB9, FTKS20/25/35CAVMB
ATKS20/25/35DAVMB
FTXS20/25/35CVMB(9)(8), ATXS20/25/35CVMB(9)
FTYN20/25/35CVMB9, FTXS20/25/35CAVMB
ATXS20/25/35DAVMB
M
FIELD PIPING
FIELD PIPING
(
6.4CuT
)
(
9.5CuT
)
7.9CuT
REFRIGERANT FLOW
FAN MOTOR
ON HEAT EXCH.
THERMISTOR
INDOOR UNIT
COOLING
7.0CuT
6.4CuT
9.5CuT
HEAT EXCHANGER
6.4CuT
6.4CuT
CROSS FLOW FAN
4D033698E
FIELD PIPING
(6.4CuT)
FIELD PIPING
(9.5CuT)
7.9CuT
CROSS FLOW FAN
FAN MOTOR
THERMISTOR
ON HEAT EXCH.
M
INDOOR UNIT
7.0CuT
6.4CuT
REFRIGERANT FLOW
COOLING
HEATING
9.5CuT
HEAT EXCHANGER
6.4CuT
6.4CuT
4D049319A
