Specifications SiBE12-933_A
28 Specifications
50Hz 220-230-240V
Model
FTXS35G2V1B FTXS42G2V1B
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 4.2kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 10.4 (367) 10.6 (374) 9.1 (321) 11.2 (395)
M 7.7 (270) 8.5 (302) 7.7 (273) 9.4 (333)
L 4.8 (170) 6.4 (226) 6.3 (221) 7.7 (271)
SL 3.5 (125) 5.4 (191) 5.4 (190) 6.8 (240)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12-0.12-0.11 0.13-0.13-0.12 0.11-0.11-0.10 0.14-0.14-0.13
Power Consumption (Rated) W 26-26-26 28-28-28 24-24-24 30-30-30
Power Factor % 98.5-94.2-98.5 97.9-93.6-97.2 99.2-94.9-100.0 97.4-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 295×800×215 295×800×215
Packaged Dimensions (H×W×D) mm 274×870×366 274×870×366
Weight kg 10 10
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 42/34/26/23 42/36/29/26 42/38/33/30 42/38/33/30
Sound Power H dBA 58 58 58 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D059724 3D059725
Model
FTXS50G2V1B
Cooling Heating
Rated Capacity 5.0kW Class
Front Panel Color White
Airflow Rates
m³/min
(cfm)
H 10.2 (360) 11.0 (388)
M 8.6 (305) 9.3 (330)
L 7.0 (246) 7.6 (267)
SL 6.0 (212) 6.7 (236)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12-0.12-0.11 0.15-0.14-0.14
Power Consumption (Rated) W 26-26-26 32-32-32
Power Factor % 98.5-94.2-98.5 97.0-99.4-95.2
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 295×800×215
Packaged Dimensions (H×W×D) mm 274×870×366
Weight kg 10
Gross Weight kg 13
Operation
Sound
H/M/L/SL dBA 43/39/34/31 44/39/34/31
Sound Power H dBA 59 60
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D059726
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
