11
12
Wall-Mounted Type
6.0 kW class
FTKD60FVM
5.0 kW class
FTKD50FVM
7.1 kW class
FTKD71FVM
2.5 kW class
FTKD25DVM
3.5 kW class
FTKD35DVM
Flat panel can be cleaned
with just a single pass of a
cloth across its smooth
surface.
FTKD25D
37/28/25 dB (A)
FTKD35D
39/29/26 dB (A)
(H/L/SL)
Wall-mounted type indoor units achieve quiet sound
levels of 25 dB (A) during Indoor Unit Quiet
Operation.
Models in the CDKD-EA series are only 700 mm in width and
21 kg in weight, so are easily installed in limited spaces. Just
200 mm in height, all models can be installed in rooms with
as little as 240 mm depth between the drop ceiling and ceiling
slab, making them ideal for even shallow ceilings.
Quiet operation sound level of only 29 dB (A) is
achieved for 2.5 and 3.5 kW class models.
* Locally obtained parts
1. To prevent an increase in operation noise, avoid installing the air suction
grille directly below the suction chamber.
2. Grilles, piping connections, ducts, and installation parts should be
obtained locally.
Duct-connected types do not have drain-up pumps.
3. The signal receiver unit must be located near the air suction inlet,
because the unit includes a sensor that detects room temperature.
Suction grille
(KDGF19A45)
Option
Signals from the wireless remote controller
are transmitted to the signal receiver.
240 mm
200 mm
Only 700 mm
Notes:
AIR
AIR
Air suction
grille*
Signal
receiver
Air discharge
duct*
Suspension bolt*
Air discharge
grille*
Signal receiver wire
Length
=
1,900 mm
Chamber
Air filter*
700 mm width type
900/1,100 mm width type
CDKD-EA
2.5
kW class
3.5
kW class
5.0
kW class
6.0
kW class
CDKD25EAVM CDKD35EAVM
CDKD25CVM CDKD35CVM CDKD50CVM CDKD60CVM
Product lineup Product lineup
Duct-Connected Type
Vertical and horizontal airflow is controlled
by Power-Airflow Dual Flaps and Wide-
Angle Louvres working in tandem, realising
even distribution of air.
The Power-Airflow Dual Flaps flatten out to deliver air to the
farthest corners of the room.
Uses a Titanium Apatite Photocatalytic Air-Purifying
Filter. Titanium apatite is a photocatalytic material
with high adsorption power. It effectively adsorbs
and removes bacteria. This filter is available for
FTKD50/60/71F.
Evenly distributed air Clean air
Slim and compact design
Quiet operation
Easy cleaningQuiet operation
Dimensions (H x W x D)
Weight
Airflow rate (H)
External static pressure
200 x 700 x 620 mm
21 kg
8.7 m
3
/min
35 Pa
200 x 900 x 620 mm
25 kg
40 Pa
CDKD25EA CDKD35EA CDKD25C
CDKD35C
9.5 m
3
/min 10 m
3
/min
Titanium Apatite
Photocatalytic
Air-purifying Filter
Air filter
Catches dust
