ESiEN02–01A Disassembly and Maintenance: Outdoor Units
Part 5 – Disassembly and Maintenance 5–25
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
A1 Compressor E20 Fan motor
A2 Rubber cushion pre-assy E22 Thermistor clamp
A3 Hexagon bolt E23 Coil motorized valve
A4 Round plain washer for wood F3 Side plate right
A5 Insulation cover F4 Side plate left
A6 Head cover F5 Front plate upper
A7 Insulation cover F6 Front plate lower
A8 Crankcase heater F7 Front plate lower
B1 Heat exchanger assy F8 Fan motor base
B1.1 Distributor assy F9 Upper stay
B2 Liquid receiver assy F10 Bypass prevention plate
B3 Filter F11 Support rear
B4 Low-pressure switch F12 Support front
B5 Stop valve assy F13 Top plate air outlet
B6 Packing for flange F14 Discharge grille
B7 Hexagon bolt F15 Suction grille
B8 Check valve F16 Stop valve mounting plate assy
B8.1 Fitting body F17 Cover
B8.2 Valve core F18 Bottom plate (sheet metal)
B8.3 Service port F19 Foundation leg
B9 High-pressure switch F20 Thermistor mounting spring
B10 Motor operated valve body F21 Thermistor mounting spring
B11 Solenoid valve body F23 Trough hole cover
B12 Solenoid valve coil K1 DAIKIN name plate
B13 Filter K3 Supplied pip (gas side)
B14 Stop valve assy K3.1 Mating flange
C1 Fan blade assy K3.2 Packing for flange
C1.1 Set screw K4 Supplied pipe (gas side)
E1 Switch box assy L1.1 Wire harness
E2 Switch box main body L1.2
E3 Switch box cover assy L1.3
E4 PCB assy L1.4
E4.1 Glass tube fuse L1.5
E5 Magnetic contactor / Electromagnetic
switch
L1.6
E6 Terminal and cover L1.7
E7 PCB assy L1.8
E8 Locking guard spacer L1.9
E9 Resin PCB support L1.10
E11 Capacitor L1.11
E12 PCB assy L1.12
E13 Power supply transformer L1.13
E15 Power supply fixing case L1.14
E16 Air thermistor L1.15
E17 Heat exchanger thermistor L1.16
E18 Discharge thermistor L1.17
E19 Fan motor L1.18
