• Split Sky Air • Outdoor Units
397
• Outdoor Units • R-410A • RKS-DVMB
2 Specifications
2-1 TECHNICAL SPECIFICATIONS
RKS20DVMB RKS25DVMB RKS35DVMB
Casing Colour Ivory White
Dimensions Packing Height mm 589 589 589
Width mm 882 882 882
Depth mm 363 363 363
Unit Height mm 550 550 550
Width mm 765 765 765
Depth mm 285 285 285
Weight Machine Weight kg 30 30 32
Gross Weight kg 35 35 38
Heat Exchanger Dimensions Length mm 828 828 805
Nr of Rows 1 1 2
Fin Pitch mm 1.40 1.40 1.40
Nr of Passes 1.8 1.8 3.1
Nr of Stages 24 24 24
Tube type Hi-Xa(7)
Fin Type WF fin WH fin WF fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller
Air Flow Rate
(nominal)
Cooling m
3
/min 36.2 36.2 33.5
Heating m
3
/min 25.7
MotorQuantity111
Model D23B-28
Motor Speed (nominal
at 230V)
Cooling rpm 860 860 860
Fan Motor Output W 31 31 31
Compressor Quantity 1 1 1
Motor Model 1YC23NXD#A
Type Hermetically sealed swing compressor
Motor
Output
W 600 600 600
Operation Range Cooling Min °CDB -10.0 -10.0 -10.0
Max °CDB 46.0 46.0 46.0
Sound Level
(nominal)
Cooling Sound
Power
dBA 61.0 61.0 62.0
Sound
Pressure
dBA 46.0 46.0 47.0
Refrigerant Type R-410A
Charge kg 0.80 0.80 1.00
Control Motor operated expansion valve
Refrigerant Oil Type FVC50K
Charged Volume l 0.4 0.4 0.4
Piping
connections
Liquid (OD) Diameter
(OD)
mm 6.35 6.35 6.35
Gas Diameter
(OD)
mm 9.5 9.5 9.5
Drain Diameter
(OD)
mm 18 18 18
Piping Length Maximum m 20 20 20
Additional Refrigerant Charge kg/m 0.02/>10 0.02>10 0.02/>10
Max. internunit level difference m 15.0 15.0 15.0
Heat Insulation Both liquid and gas pipes
Standard
Accessories
Item Installation manual
Quantity 111
RKS-DVMB.book Page 397 Thursday, June 9, 2005 5:08 PM
