Outdoor Unit SiBE04-302
172 Removal Procedure
2.8 Removal of Compressor
Procedure Warning Be sure to turn off all power supplies at least 10 min. before disassembling work.
Step Procedure Points
1. Remove the parts around
the compressor.
Be careful so as not to burn
the compressor terminals or
the name plate.
1
Remove the terminal
cover and the lead
wires of the
compressor so as not
to be burnt out by a gas
brazing machine.
