ELECTRICAL JIG SAW

OPERATION

ATTENTION!

Always disconnect the power cable from the electrical outlet before preparing for the

operation, adjustment, maintenance of power tools.

Installation / removal of the tooling

ATTENTION!

When installing, removing, replacing the tooling disconnect the power plug. Accidental

switching on of the machine when changing accessories may cause signicant injury.

Use saw blades suitable for the material being processed. The use of metal blades in the processing of wood will

reduce productivity, the use of wood blades in metal processing will lead to tool breakage.

Before installing the blade, always clean the blade and blade holder. Sawdust and other foreign objects may cause

poor xation of the blade, which can lead to its breakdown, as well as to an accident.

The blade is installed in the jigsaw "teeth forward". Incorrect installation of the blade leads to the jigsaw breakage.

When installing the blade make sure that its end enter the groove of the support roller 9 (рiс. 1).

Use only single-shank blades (shank Т). The length of the blade should not exceed the length necessary for the

intended cut. For curly cuts with a small radius use narrow saw blades.

The blade is fixed in a keyless self-locking lock 10 (рiс. 1). To install the blade you need to turn the dust cover

3 (рiс. 1) in the upper position, turn the lock lever of blade mount until it stops , insert the blade into the socket

also until it stops and release the lock lever. The removal of the blade is carried out in reverse order.

Power connection

ATTENTION!

The electric tools should be connected only to the single phase AC which voltage corresponds

to the voltage indicated on the table of characteristics, placed on the tool housing. If the rating

plate indicates the voltage of 230V, then the power tool can also be switched on to a network

with a voltage of 220V.

When working outdoors use industrial extension cords intended for outdoor use. Do not use homemade

extensions. When working outdoors connect power tools to the power circuit equipped with a dierential

automatic with a response current of not more than 30 мА, this will reduce the risk of electric shock.

When connecting ensure that the insulation of the electrical cable and the power plug of the machine is intact.

Make sure the machine's power switch is in the “o” position.

This power tool can be connected to power outlets that do not have a protective ground, since it has double

insulation (protection class II).

Cutting speed adjustment

Depending on the type of tooling used and the type of material being processed you can choose the optimal

speed of the blade. Adjustment is carried out from minimum to maximum value indicated in the table 1, by

turning the speed controller 1 (рiс. 1). The numbers on the regulator ring correspond to the ring positions and do

not indicate the specic frequency of the blade per minute.

It is possible to change the speed while the engine is running, including under load. Increasing the cutting speed

reduces the cutting time, but leads to a decrease in the life of the blade.
