Daikin FTK25JAV1NB [5/29] Specifications
![Daikin FTX35JAV1NB [5/29] Specifications](/views2/1781990/page5/bg5.png)
2
Specifications
NOMINAL CAPACITY and NOMINAL INPUT
For indoor units only:
INDOOR UNITS FTK25JAV1NB FTK35JAV1NB FTK50HV1NB FTK60HV1NB
NOMINAL INPUT Cooling kW 0.04 0.04 0.05 0.06
For combination indoor units + outdoor units:
INDOOR UNITS FTK25JAV1NB FTK35JAV1NB FTK50HV1NB FTK60HV1NB
OUTDOOR UNITS RK25JV1NB RK35JV1NB --
NOMINAL CAPACITY (2-3) Cooling (1) min.∼nom.∼max. kW 1.30∼2.50∼3.00 1.40∼3.54∼3.80 For capacities and power input in multi model application, see
chapter MK-H
NOMINAL INPUT Cooling min.∼nom.∼max. kW 0.43∼0.945∼1.250 0.47∼1.345∼1.72
TECHNICAL SPECIFICATIONS
INDOOR UNITS FTK25JAV1NB FTK35JAV1NB FTK50HV1NB FTK60HV1NB
DIMENSIONS Unit H mm 273 273 298 298
W mm 784 784 1,050 1,050
D mm 185 185 190 190
WEIGHT Unit kg 7.5 7.5 12 12
COLOUR Unit Almond white
SOUND LEVEL Sound pressure (4) high dBA 38 39 44 46
medium dBA 32 33 39 42
low dBA 26 27 35 38
Sound power (5) dBA 54 55 60 62
FAN Air flow rate high m
3
/min 7.1 7.4 12.9 14
medium m
3
/min 5.9 6 11.2 12.1
low m
3
/min 4.6 4.7 9.4 10.3
Speed steps 5 steps and auto
high rpm 1,260 1,300 1,240 1,320
medium rpm 1,075 1,100 1,120 1,180
low rpm 890 900 1,000 1,040
Type Cross flow fan
Qty x model 1 x 18F-22 1 x 18F-22 1 x D40A-05 (DC-Motor) 1 x D40A-05 (DC-Motor)
Qty x motor output W 1 x 18 1 x 18 1 x 35 1 x 35
HEAT EXCHANGER Type J7 Hi-XA tube
Rows x stages x fin pitch mm 2 x 12 x 1.4 2 x 12 x 1.4 2 x 14 x 1.2 2 x 14 x 1.2
AIR FILTER Removable/washable/mildew proof
AIR DIRECTION CONTROL Right, left, horizontal and downward
TEMPERATURE CONTROL Microcomputer control
PIPING CONNECTIONS liquid mm J 6.4 J 6.4 J 6.4 J 6.4
gas mm J 9.5 J 12.7 J 12.7 J 15.9
drain mm J 18.0 J 18.0 J 18.0 J 18.0
INSULATION MATERIAL Heat insulation tape Both liquid and gas pipes
For outdoor units Pair application See chapter RK-J
Multi model application See chapter MK-H
3D027499B
3D027500B
3D013612B
3D013616B
•
Wall Mounted Inverter Controlled Unit •
R-22 •
FTK/FTX-JA/FTX-H/FTXD-J
2
2
3
• Split - Sky Air • Indoor Units
