- 20 -
USING
European).
1. Ensure that the ON/OFF Power Button (1) is
in the OFF position and the product is unplugged
from the electrical outlet.
2. Raise the Needle (24) to its highest position
by turning the Hand Wheel (4).
3. Loosen the Needle Clamp Screw (23) by turning
it counterclockwise (toward you).
4. Gently pull down on the Needle (24) until it is
clear of the clamp.
5. Replace the needle in the slot and tighten the
Needle Clamp Screw (23).
NOTE: When replacing the Needle (24), ensure
that the flat side on the upper portion of the
Needle (24) (the part that slides into the slot)
faces inward, toward the Needle Clamp Screw
(23).
Using the Speed Button (2):
Depress the Speed Button (2) for a slower sewing speed. This is the best speed for sewing
heavier fabrics. When the Speed Button (2) is not depressed, the machine runs at a faster
speed for sewing lighter fabrics.
Winding the Bobbin:
To maintain even stitching while sewing, the Bobbin thread should always be the same
weight as the Thread Spool.
1. Ensure that the ON/OFF Power Button (1) is in the OFF position.
2. Remove the Bobbin Cover Plate (25) by pressing the Bobbin Cover Button (28); remove
the empty Bobbin (29).
3. Place a spool of thread onto the Top Spindle (11) and put the end of the thread through
one of the holes in the Bobbin and wind it around the Bobbin (29) several times to anchor
the thread.
4. Place the Bobbin (29) firmly onto the Rewind Spindle (3).
5. The next step requires you to do several things very quickly in order to load the Bobbin
(29) evenly.
a. Press the ON Button and then immediately begin guiding the thread evenly onto the
Bobbin (29).
NOTE: The Bobbin thread must be wound evenly onto the Bobbin (29) to ensure smooth
stitching.
b. To keep the Bobbin (29) from slipping off the Rewind Spindle (3), it may be necessary
to press your finger lightly on the Bobbin as thread is loaded onto the Bobbin (29).
Needle thread
hole
Thread
Guide
4
Needle Clamp Screw
Needle Clamp
Needle with flat side
facing right toward
the needle Clamp
Screw
Presser foot
Flat side of Needle
Top
NOTE:Flat side of the
needlefaces toward
the needle Adjustment
Screw when installed.
