HOUSING - DRIVE SIDE - MW 240/240P

Truvox International Limited

MW240/240P

SL.NO PART NO DESCRIPTION SIZE QTY

1 90-0258-0000 CSK SCREW M4X10 4

2 90-0001-0000 CRPH SCREW M3X6 6

7 90-0143-0000 CSK SCREW M6X14 2

9 90-0293-0000 ALLEN SCREW M6X10 2

10 90-0144-0000 ALLEN SCREW M6X16 7

11 90-0005-0000 ALLEN SCREW M6X20 2

19 02-3847-0000 BEARING 6003 2RS 8

20 90-0598-0000 BUSH SHAFT MOTOR 1

24 90-0011-0000 BELT 500 5 M 1

25 90-0012-0000 BELT 425 5 M 1

28 90-0152-0000 WASHER 2

32 90-0154-0500 BUMPER FRONT 1

34 90-0156-0000 BUMPER COVER 1

39 90-0154-0000 STUB AXLE 1

42 90-0024-0500 BRUSH SLIDER - TEAL 1

43 90-0025-0000 SLIDER HOUSING 1

46 90-0027-0000 SEAL 2

59 90-0035-0000 PIN 1

62 90-0176-0000 O' RING 1

63 90-0040-0000 SHIELD 1

77 90-0020-0000 CAP 2

92 90-0267-0000 SHIELD 2

93 90-0294-0000 ROLLER 1

111 90-0061-0000 BRUSH SPROCKET 2

114 90-0063-0000 GEAR SPROCKET 2

115 90-0065-0000 IDLER ASSY 1

116 90-0197-0000 IDLER ASSY 1

260 90-0499-0000 DRUM PINION ASSY 1

311 90-0651-0000 HOUSING ASSY - GEAR SUPPORT 1

395 90-0650-0000 GEAR - LH & RH NEW - KIT 1

V7 90-0329-0500 DRIVE HOUSING - BLACK 1

V8 90-0126-0500 COVER - BLACK 1
