CIMEX CYCLONE
The following manual contains important
information about the machine and safety advice
for the operator.
WARNING
Earth Ground Symbol
Waste Electrical & Electronic
Equipment (WEEE)
Do not dispose of this device with
unsorted waste. Improper disposal may
be harmful to the environment and
human health. Please refer to your
local waste authority for information on
return and collection systems in your
area.
EC DECLARATION OF CONFORMITY
Machine Type: Three Brush
Type: Cimex Cyclone
Model: CR38…,
CRS38…, CR48…,
CR48/DF…
This machine is in conformity with the following EU
directives:
2006/42/EC
2004/108/EC
Applied
harmonised
standards
Machinery Directive
The EMC Directive
EN60335-1, EN60335-2-67,
EN55014-1, EN55014-2,
EN610003-2, EN610003-3,
EN62233
Truvox International
Malcolm Eneas
Unit C (East) Hamilton
Business Park, Manaton
Way, Botley Road, Hedge
End, Southampton,
SO30 2JR, England
Operations Manager
Southampton, 30-04-2004
TECHNICAL SPECIFICATIONS
Model
Cyclone
38
Cyclone
38
Cyclone
48
Diamond
Finisher
48
Product Code
CR38 CRS38 CR48
CR48
DF
Voltage AC
(~)/ Frequency
V/
Hz
230/ 50 -
Motor power W 370 550 -
Motor power
(single phase/
three phase)
W - 1500/-
Solution tank
capacity
l 25 -
Working width cm 38 48 -
Pad/brush
speed
rpm 620 400 880
Pad/brush
pressure
g/cm
²
45 38 -
Pad/brush
diameter
cm 16.5 20 48
Productivity m²/h - 600
Productivity -
Scrubbing
m²/h 1140 - 1140 -
Productivity -
Polishing
m²/h 1710 - 2160 -
Productivity -
Spray clean
m²/h 850 - 1080 -
Productivity -
Shampooing
m²/h - 1140 -
Sound
pressure level
dB
(A)
60 -
Dimensions
(L x W x H)
cm 74 x 40 x 112
80 x
50 x 112
-
Weight kg 38 47 60
Ballast
weights
kg - 17
No. units
supplied
- 2
Cable length
m
15
Warranty 1 year
•
Machine is of Class I construction. Enclosure to IPX4.
Models –
110V & 230 V ~ 50 Hz. fitted with 15m supply
cord type H05VV-F 3x1.0mm² (10A), and plug.
• Sound pressure levels measured at a distance of 1 metre
from machine and 1.
6 metres above the floor, when
scrubbing a hard floor. Measurements recorded using a
hand held meter.
• Handle vibration does not exceed 2,5m/s², when operating
on any surface with brush or pads. Measurements
recorded by an independent test laboratory.
• All machines supplied with two 17kg weights.
If you have any queries or questions, please contact
the supplier who you purchased the machine from or
Truvox International.
Truvox International Limited
Unit C (East) Hamilton Business Park, Manaton Way,
Botley Road, Hedge End, Southampton, SO30 2JR,
United Kingdom; Tel.: +44 (0) 23 8070 6600;
Fax: +44 (0) 23 8070 5001; Email: sales@truvox.com;
Web: www.truvox.com
ORIGINAL INSTRUCTIONS
WARNING - READ THESE INSTRUCTIONS BEFORE USING THE MACHINE & RETAIN FOR FUTURE REFERENCE
