8
9. Accessories
Item
CR38 (16cm)
CR48 (20cm)
CR48/DF
Usage
Polypropylene brush (yellow)
11-1604-0500
11-2004-0500
-
Medium scrubbing
Nylon brush (white)
11-1605-0500
11-2005-0500
-
Standard scrubbing
Shampoo brushes (white)
11-1607-0500
11-2007-0500
-
Drive disc
11-1662-0500
11-2062-0500
-
Fibre (biscuit)
-
11-2001-0500
-
General purpose
scrubbing
Polypropylene brush (yellow)
-
11-2003-0500
-
Light scrubbing
Bronze/Polypropylene mix
brush (white/bronze)
-
11-2013-0500
-
Abrasive scrubbing
Tynex brush (grey)
-
11-2016-0500
-
Extra heavy duty
scrubbing
Velcro drive disc
-
11-2060-0500
-
Crimped wire
-
-
11-2041-0500
Chequer plate cleaning
Steel wire 18G
-
-
11-2043-0500
Concrete finishing
Bronze wire 18G
-
-
11-2045-0500
Spark-free scarifying
Steel wire 3x 16G
-
-
11-2049-0500
General scarifying
Steel wire 3x 14G
-
-
11-2051-0500
Heavy duty scarifying
Velcro drive back
-
-
05-4346-0000
For diamond tooling
NOTE - Brushes are supplied in sets of 3.
10. Fault diagnosis
The following simple checks may be performed by the operator:
Trouble
Reason
Remedy
Motor not running
• Lack of voltage/ electrical
supply
• Safety cut-out switch faulty
• Check fuse *, supply cord, plug,
socket outlet and circuit breaker
Machine stalls during operation
• Damaged brushes/ pads
• Replace brushes/ pads
Motor running, but brushes not
rotating
• Loose or broken drive belt
• Remove rotating dust cover and
fit new drive belt, or call Service
Agent
Machine vibrates
• Damaged or dirty brushes/
pads
• Unequal thickness of brushes/
pads
• Replace or clean brushes/ pads
• Replace with 3 brushes/ pads of
equal thickness
Cleaning solution not flowing
• Dirt in tank, outlet blocked
• Flow valve not open
• Flush out tank with clean water
• Check all valves are open
* If the fuse blows several times, the machine should be checked by an authorised Service Agent.
