Introduction ESiEN02–01A
x
3
1
4
5
1.2 Combination Overview: Outdoor Units other than the Sky Air B-Series
Introduction In the table in this section:
■ The units in grey boxes are described in ESIE99–01.
■ “(o.m.)” stands for old model. These are not described in this manual.
■ “M” stands for multi combination.
■ “P” stands for pair combination.
■ “T” stands for twin, triple or double twin combination.
Combination table The table below contains the possible combinations between Sky Air B-series indoor units and outdoor
units other than the Sky Air B-series.
FHC35BZ7V1
FHC45BZ7V1
FHC60BZ7V1
FHYC35BZ7V1
FHYC45BZ7V1
FHYC71BZV1
FHYC100BZV1
FHYC125BZV1
FH35BZV1
FH45BZV1
FH60BZV1
FHK35BZV1
FHK45BZV1
FHK60BZV1
Split
Small
c/o
R35E(A)Z7V11(o.m.)
R35GZ7V11
P
— — — — — — —
P
— —
P
— —
R45E(A)Z7V11/W11(o.m.)
R45GZ7V11/W11
—
P
— — — — — — —
P
— —
P
—
R60GZ7W1
— —
P
— — — — — — —
P
— —
P
MA56GZ7W11
M M
— — — — — —
M M
—
M M
—
MA90GZ7W11
M M M
— — — — —
M M M M M M
Small
h/p
RY35E(A)Z7V1 — — —
P
— — — — — — — — — —
RY45E(A)Z7V1
— — — —
P
—————————
Sky Air G -series
Large
c/o
R71GZV1/W1/T1 — — —
T
—
P
— — — — — — — —
R100GZ7V1/W1/T1 — — —
T T T P
— — — — — — —
R125GZ7W1/T1 — — —
T T T
—
P
— — — — — —
Large
h/p
RY71GZ7V1/W1 — — —
T
— — — — — — — — — —
RY100GZ7V1/W1 — — —
T T
— — — — — — — — —
RY125GZ7W1 — — —
T T
— — — — — — — — —
Outdoor unit
Indoor unit
