14
Wiring adapter for time clock KRP413A1S
(normal open contact/normal open pulse contact)
Centralised control board - up to 5 rooms (1) KRC72
Central remote control (1) DCS302B51
Unified ON/OFF control (1) DCS301B51
Schedule timer (1) DCT301B51
Interface adapter (DIII-net) KRP928A1S
(1) Wiring adapter is also required for each indoor unit
FTK/FTX25-35AZ FTK/FTX50-60-71AZ
Photocatalytic deodorising filter, with frame - KAZ917B41
Photocatalytic deodorising filter, without frame KAZ962A42 KAZ917B42
Combined air purification filter KAZ926B41 -
+ photocatalytic deodorising filter
Air purification filter with frame - KAF925B41
Air purification filter without frame KAF926B42 KAF925B42
Anti theft protection for remote controller KKF917A4 KKF917A4
ACCESSORIES
OTHER ACCESSORIES
CONTROL SYSTEMS
An infrared remote control will be standard provided with the indoor unit.
