- 12 -SJ 3125 INSTRUCTION MANUAL

ASSEMBLY

the juice container under the nozzle on the right of the machine.

3. Attach the residue container onto the main body and clip the filter net into

place.

4. Attach the top transparent cover and close and place the juicer stick in the

food chute.

5. Make sure the housing unit is locked with the safety lockers in place by

hooking them onto the top cover and pushing them downwards until they clip

in place.

6. The juicer will not work for safety reasons if the safety lockers are not

locked in place correctly.

DISASSEMBLY

1. Remove the juicer stick and the pulp and juice containers.

2. To remove the upper body pull both safety lockers outwards from the

bottom. Release and lift off the top cover.

3. Lift the filter net off by gently pulling upwards.

4. Lift of the Residue container.

Juicing

1. Assemble the machine as described above.

2. Connect to mains supply.

3. Remove the Juicer Stick (it simply lifts out).

4. Ensure the juicer and pulp containers are in place.

5. Start the machine using the power switch and turning it to position 1 for

slow and position 2 for fast.

6. Slowly add the fruit/vegetable pieces via the food chute using the Juicer

Stick to feed the fruit down the chute. Please remember to remove any large

stones in fruit or any peel that you would not normally eat.

7. The juicer is efficient but do not to over load the machine by feeding too

much through at once.

8. Once the juice container is full you can empty the juice into another container

and then resume juicing.

9. Once the Pulp container is full, switch of the juicer at the mains supply and

disassemble as described above. Empty the sediment from the sediment

container and re-assemble as described above. Switch on the mains supply,
