Feature
For your comfort and energy
saving
Other functions
COMFORT AIRFLOW OUTDOOR UNIT QUIET ECONO
The airow direction will be in upward
while in COOL operation, in downward
while in HEAT operation. This function
will prevent cold or warm air from
directly blowing on your body.
Page 15
OUTDOOR UNIT QUIET operation
lowers the noise level of the outdoor
unit. This function is useful when you
need to consider the noise for your
neighbourhood.
Page 19
This function enables efcient operation
by limiting the maximum power
consumption. It is useful when using the
air conditioner and other electrical
devices simultaneously.
Page 19
INTELLIGENT EYE
The INTELLIGENT EYE sensor detects the human movement in
a room. If no one is in the room for more than 20 minutes, the
operation automatically changes to energy saving operation.
Page 15
WEEKLY TIMER
Up to 4 timer settings can be saved for each day of the week
according to your family’s life style. The WEEKLY TIMER allows
you to set on/off time and the desired temperature.
Page 23
