![Daikin FHYC50JEVLK Инструкция по монтажу онлайн [16/32] 603778](/views2/1785168/page16/bg10.png)
1-14
COMP
L
N
COMP
L
N
L
N
FHC40JEVLK - RD40JEVLK
Model Indoor FHC40JEVLK
Outdoor RD40JEVLK
Voltage range** Indoor
220V/1Ph/60Hz +
!
Outdoor
220V/1Ph/60Hz +
!
Power supply cable size* mm
2
Number of conductors
6.0
3
Interconnection cable size* mm
2
Number of conductors
2.5
4
Recommended time delay fuse* A 35
COMP
L
N
COMP
L
N
R
S
T
FHC50JEVLK - RD50JETLK
Model Indoor FHC50JEVLK
Outdoor RD50JETLK
Voltage range** Indoor
220V/1Ph/60Hz +
!
Outdoor
220V/3N~/60Hz +
!
Power supply cable size* mm
2
Number of conductors
6.0
3
Interconnection cable size* mm
2
Number of conductors
2.5
4
Recommended time delay fuse* A 35
There must be an all pole
disconnection in the supply
mains with a contact separation
of at least 3mm.
Interconnection Cable
Indoor Unit
Terminal Block
Outdoor Unit
Terminal Block
Power Supply Cable
Interconnection Cable
Indoor Unit
Terminal Block
Outdoor Unit
Terminal Block
Power Supply Cable
There must be an all pole
disconnection in the supply
mains with a contact separation
of at least 3mm.
EN CKE-0911(0)DK(saso).indd 14 12/6/11 3:05:10 PM
