![Daikin FHC50JEVLK Инструкция по монтажу онлайн [18/32] 603773](/views2/1785168/page18/bg12.png)
1-16
COMP
A
OF
4WV
L
N
R
T
S
COMP
A
OF
4WV
L
N
COMP
A
OF
4WV
L
N
COMP
A
OF
4WV
L
N
L
N
FHYC40JEVLK - RYD40JEVLK
FHYC50JEVLK - RYD50JETLK
Indoor Unit
Terminal Block
Interconnection Cable
Outdoor Unit
Terminal Block
Power Supply Cable
Model Indoor FHYC50JEVLK
Outdoor RYD50JETLK
Voltage range** Indoor
220V/1Ph/60Hz +
!
Outdoor
220V/3N~/60Hz +
!
Power supply cable size* mm
2
Number of conductors
6.0
3
Interconnection cable size* mm
2
Number of conductors
2.5
4 & 3
Recommended time delay fuse* A 35
Model Indoor FHYC40JEVLK
Outdoor RYD40JEVLK
Voltage range** Indoor
220V/1Ph/60Hz +
!
Outdoor
220V/1Ph/60Hz +
!
Power supply cable size* mm
2
Number of conductors
6.0
3
Interconnection cable size* mm
2
Number of conductors
2.5
4 & 3
Recommended time delay fuse* A 35
Outdoor Coil Sensor
Interconnection Cable
Indoor Unit
Terminal Block
Outdoor Unit
Terminal Block
Power Supply Cable
There must be an all pole
disconnection in the supply
mains with a contact separation
of at least 3mm.
There must be an all pole
disconnection in the supply
mains with a contact separation
of at least 3mm.
Outdoor Coil Sensor
EN CKE-0911(0)DK(saso).indd 16 12/6/11 3:05:10 PM
