REMOTE CONTROLLER LOSS PREVENTION WITH BALL CHAIN

(OPTIONAL)

Remote controller

Screw

Wall attachment screw

Holder

Ball chain (350mm)

iii

Installation

1. Match the ring at the end of the ball chain with the screw hole on the back of the remote

controller and secure it with the screw.

2. Attach the holder and the ball chain as above at the position where signals from the

remote controller can be received easily.

3. Pass the ball chain through the back of the holder and match the ring at the end of the

ball chain to the upper hole of the holder. Fix the holder to the wall by putting through

2 screws across it.
