2
1.1 ON/OFF Button
• Starting Operation:
When the unit is turned off, press the ON/OFF button.
The operation LED lights and the unit is turned on.
• Stopping Operation:
When the unit is turned on, press the ON/OFF button. The operation LED is extinguished
and control are turned off.
1.2 SLEEP Button
Press SLEEP button to activate the sleep mode or energy saving mode.
1.3 FAN Button
Press FAN button to select
AUTO, HIGH, MEDIUM or LOW fan speed.
1.4 MODE Button
Press the MODE button to switch operation from
COOL, HEAT, AUTO, DRY, FAN.
The Auto mode is unavailable for Chilled Water (CW) system.
Check the display to see in which mode the control is set.
1.5 ‘!’ or ‘"’ Set Temperature Button
Press the temperature button and set the temperature of your choice. By pressing the ‘!’ or
‘"’ button once, temperature changes by 1°C [or 1°F].
Temperature can be set within the range 16°C~30°C (61°F~86°F) or 20°C~30°C (68°F~86°F).
The range can be set by adjusting the shunt jumper behind the LCD remote (refer table below).
During fan mode, temperature can not be set.
If pressing ‘!’ and ‘"’ together, the unit of temperature will change from °C to °F and
vice-versa.
1.6 SWING button
Press SWING button to activate the air sweep function. This mode is not applicable for ducted
models.
1.7 Time Setting
i) Set Real Time Clock Setting
Press CLOCK key one time will activate RTC setting mode. Pressing the same key again
will disable RTC setting mode.
Under RTC setting mode, “SET CLOCK” will be shown on LCD and it will blink at 0.5 sec
interval. The RTC and Day setting can be changed by pressing DAY key, HOUR key or
MINUTE key. If there is no further time related (DAY, HOUR and MINUTE) key is pressed
for 15 sec, the unit will quit from the CLOCK setting mode.
ii) 7-Day Programmable Timers
The unit has 3 event functions, each event has an ON TIMER and an OFF TIMER.
Press the timer key (ON TIMER or OFF TIMER) will enable Event 1 timer setting mode.
Press the same key again will enable Event 2 timer setting mode. Press the 3rd times will
enable the Event 3 (Event handset) timer- setting mode. Subsequent key pressed the unit
will quit from timer setting mode.
All timers are event triggered timers and can be overridden by the ON/OFF button and
Override function.
iii) Set Event 1 and Event 2 Timers
Under timer setting mode, “SET TIMER” will be shown on LCD and blink at 0.5 sec interval.
For Event 1 Timer setting, ‘
ON’ or ‘ OFF’ indication will appear and digit “1” will be
displayed on the top left corner of the LCD. ‘ ON’ or ‘ OFF’ indication and digit “2”
will be displayed during Event 2 timer setting. The timer setting can be changed through
pressing the DAY key, HOUR key or MINUTE key. If there is no further time related (DAY,
HOUR and MINUTE) key is pressed, the unit will quit from the timer setting mode.
Jumper 20 - 30 Application
SET Set temp range : 20°C ~ 30°C (68°F ~ 86°F)
OFF Set temp range : 16°C ~ 30°C (61°F ~ 86°F)
